4.50 Inch Rotatable Bored Conflat Flange with 8 Tapped Bolt Holes - Stainless Steel UHV Vacuum Fitting(CF50-1.5")

DescriptionThese are Bored Through 8 bolt holes rotatable flanges, 4.50 inch CF, CFF ConFlat (CF). These flanges are used for ultra-high vacuum applications. These fittings use a copper gasket and a knife-edge flange to achieve the high vacuum seal and can operate down to 10-13 torr (10-11 Pa) and can be to 450 °C for bake-out.These vacuum fittings are made of resistant stainless steel. These single-sided rotatable ultrahigh vacuum (UHV) CF flanges feature tapped or thru bolt holes and are joined to non-rotatable CF flanges. Rotatable CF flanges simplify alignment with the bolt holes of other system components and give infinitely rotatable joints.Copper gaskets make CF flanges self-centering and the standard leak grooves simplify troubleshooting and gasket removal.DetailsRotatable single-sided CF flangeCompatible with standard inch tubing diametersTapped or thru flange bolt holesCF 4.50-Inch Flanges & CF63 ConnectionsTapped 8 bolt HolesCommon DimensionsA) Outer Diameter = 4.5" (113.50mm)(B) = 2.7/8"(72.39mm)(C) = 2 7/16"(62mm)(D) = 3/4"(19.10mm)(E) = 3 5/8"(92.15mm)Package :1*CF63 Rotatable Bored Conflat Flange

• Devised for ultra-high vacuum applications, this 4.50-inch rotatable CF flange ensures optimal alignment and performance.
• Constructed from -resistant stainless steel, providing durability and longevity in demanding environments.
• Features 8 tapped bolt holes for easy installation and compatibility with standard inch tubing diameters.
• Utilizes a copper gasket and knife-edge devise for a reliable high vacuum seal, capable of operating down to 10-13 torr (10-11 Pa).
• Ideal for applications requiring heating up to 450 °C for bake-out, making it versatile for various scientific and industrial uses.
